1.A true Windows 11 gaming device that comes bundled with 3 months of Game Pass for free.

2.Powered by AMD Ryzen™ Z1 Extreme processor and up to 24GB of LPDDR5X RAM, the ROG Ally X now features up to 1TB of storage. Play more games faster than ever.

3.ROG’s Zero Gravity thermal system and dual fan design keep the Ally cool and quiet in any orientation, letting you game your way.

4.A newly-optimized Armoury Crate SE interface includes a highly customizable game library with easy navigation, light and dark themes, BIOS and driver updates, and more.

5.The ROG Ally X boasts an 80Wh battery and redesigned ergonomics for long gaming sessions, as well as convenient dual USB Type-C ports.

6.A Full HD 120Hz high refresh rate display with FreeSyncTM Premium gives you a crystal clear view of the action even in fast-paced games.

Game on the go

A bigger battery unlocks all new possibilities for handheld gaming. The 80Wh battery found on the ROG Ally X is double the previous generation, providing more than 2.7 hours of heavy AAA gaming or 14.5 hours of video playback on Netflix. With the ROG Ally X, spend less time worrying about where a charger is and more time actually gaming.

2.7 hours

Heavy AAA Gaming

14.5 hours

Netflix Video Playback

Zero Gravity, Zero Distraction, 100% Performance

The ROG Ally X is designed to let you play anywhere, so it needed a thermal solution to match. It comes equipped with specially designed heatpipes that operate at peak efficiency in any orientation, and a new third exhaust vent to help keep the mainboard and panel cool.

Up to

24%

Airflow improved

Up to

6°C

Cooler touch screen

Lightning Fast. Crystal Clear.

Sporting a 1080p touchscreen panel with a 120Hz refresh rate and FreeSync™ Premium support, this 7-inch display is truly a joy to game on. While common LCD displays generally have a maximum brightness of 200-300 nits, the Ally X cranks it all the way to 500 nits. A higher brightness allows the Ally X to clearly display the action on screen when in challenging brighter environments like the great outdoors without losing access to contrast or 100% of the sRGB color space.

Refresh rate

120Hz

Full HD

1080p

7-inch

Touch Panel

Response Time

7ms

Wide Color Gamut

sRGB 100%

High Brightness

500 nits

Better Outdoor Visibility with Corning^® DXC

A Corning^® Gorilla^® Glass DXC coating reduces surface reflections while also increasing hardness by over 40% for improved scratch resistance. Fewer reflections mean you can keep track of what’s happening on-screen in bright or outdoor environments.

Gorilla^® Glass

Victus

DXC

Coating

Modern Security

Windows Hello

Log in to the Ally quickly and securely with a Windows Hello fingerprint reader integrated with the power button, no PIN required. If you accidentally leave your Ally unattended, your data is secure.

Parental Control

For younger users, parents can limit app or screen time, see spending summaries, and track their kids’ locations with powerful parental controls.

Windows Defender

Windows Defender provides robust security for your device, with constantly updated antivirus and malware protection.

Reach the Clouds with Wi-Fi 6E

The Ally was built to travel, so it comes equipped with ultra-fast Wi-Fi 6E networking. Wi-Fi 6E supports 4X more network capacity and 75% lower latency than Wi-Fi 6, letting the Ally stream videos, access cloud gaming services, and download games effortlessly even on crowded networks.

Video Streaming

Cloud Gaming

Model

ROG Ally X

Operating System

Windows 11 Home

Processor

CPU:AMD Ryzen™ Z1 Extreme Processor (“Zen4” architecture with 4nm process, 8-core /16-threads, 24MB total cache, up to 5.10 Ghz boost)

GPU:AMD Radeon™ Graphics (AMD RDNA™ 3, 12 CUs, up to 2.7 GHz, up to 8.6 Teraflops)

TDP: 9-30W

Display

7-inch

FHD (1920 x 1080) 16:9

IPS-level

glossy display

sRGB:100%

Adobe:75.35%

Gorilla^® Glass Victus™

Touch Screen (10-point multi-touch)

Refresh Rate:120Hz

Response Time:7ms

Brightness:500nits

AMD FreeSync™ Premium (Variable Refresh Rate)

Memory

12GB*2 LPDDR5 on board

Support dual channel memory

Storage

1TB PCIe^® 4.0 NVMe™ M.2 SSD (2280)

I/O Ports

1x 3.5mm Combo Audio Jack

1x USB 3.2 Gen 2 Type-C support DisplayPort™ / power delivery

1x Type C support USB 4 (Thunderbolt™ 4 compliance, DisplayPort™ 1.4 with Freesync support, Power Delivery 3.0)

1x UHS-II microSD card reader (supports SD, SDXC and SDHC)

Control and Input

View button

Menu button

L & R Hall Effect analog triggers

L & R bumpers

D-pad

Command Center button

Armoury Crate button

A B X Y buttons

2 x assignable grip buttons

Thumbsticks: 2 x full-size analog sticks

Haptics: HD haptics

Gyro:6-Axis IMU

Audio

Smart Amp Technology

Hi-Res certification (for headphone)

Dolby Atmos

AI noise-canceling technology

Built-in array microphone

2-speaker system with Smart Amplifier Technology

Network and Communication

Wi-Fi 6E(802.11ax) (Triple band) 2*2 + Bluetooth^® 5.2 (*Bluetooth^® version may change with OS version different.)

Battery

80WHrs, 4S1P, 4-cell Li-ion

Power Supply

TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal

AURA SYNC

Yes

Weight

678 g (1.49 lbs)

Dimensions (W x D x H)

28.0 x 11.1 x 2.47 ~ 3.69 cm (11.02″ x 4.37″ x 0.97″ ~ 1.45″)

Xbox Game Pass

Xbox Game Pass for PC_3 months (*Terms and exclusions apply. Offer only available in eligible markets for Xbox Game Pass for PC. Eligible markets are determined at activation. Game catalog varies by region, device, and time.)

Security

Microsoft Pluton security processor

Built-in Fingerprint Sensor
